Precision Agriculture

The FjDynamics Wireless Camera allows for crystal-clear High Definition streaming back to any FJ display. Up to two cameras are supported at any given time.
The cameras come with a 7M (22ft) power cord, and support up to a 20M (80ft) transmission distance. Extra cabling is available.

NAV-900 Generic Quick Release Solution.
Can be attached with the VHB taped mount feet for universal applications to a wide range of agricultural vehicles
Allows the multipurpose bracket(PN 109315) to be clipped in and out for easy transfer of the Guidance Controller

This is the available information regarding this cable. While Trimble has taken care to prepare this information, we cannot be responsible for its accuracy.

The information supplied is for trouble shooting purposes only and not used to construct cables. Doing so will void system warranty.

The Easy-Switch Is a foot & push button accessory which allows you to engage and disengage your autosteer system without needing to touch the screen.
This kit includes the accessory harness, the foot switch, and the push button. You can use either, or both as necessary in your application.

Trimble Field-IQ & ISOBus Dual Relay Power Cutoff Cable

Used for Full Harness Tractor ISOBus Kits.

Note: The cable schematic information was best available at time of posting, however modifications in production can occur.
The information supplied is for troubleshooting purposes only, it is not intended to be used to construct cables.Doing so will void system warranty.

EZ-Steer Platform Kit - Steigers, Versatile
This bracket attaches to the vehicle steering column to provide support for the steering motor for either the Trimble® AgGPS® EZ-Steer® assisted steering system or the EZ-Steer 500 system.
Supported Vehicles:
Case IH Stieger 9110
Case IH Stieger 9130
Case IH Stieger 9150
Case IH Stieger 9170
Case IH Stieger 9180
Case IH Stieger 9210
Case IH Stieger 9230
Case IH Stieger 9240
Case IH Stieger 9250
Case IH Stieger 9260
Case IH Stieger 9270
Case IH Stieger 9280
Case IH Stieger 9310
Case IH Stieger 9330
Case IH Stieger 9350
Case IH Stieger 9370
Case IH Stieger 9380
Case IH Stieger 9390

The Radar-Out harness allows you to send square-wave radar speed signals to either an aftermarket rate controller, or the machine's built in computer, replacing the bulky radar attached to the unit.

The EasySwitch is a Push-Button switch which can be integrated into the armrest, joystick, or console of a machine to allow for rapid, easy engagement of the autosteer without the use of the touch screen.

Note: The cable schematic information was best available at time of posting, however modifications in production can occur.
The information supplied is for troubleshooting purposes only, it is not intended to be used to construct cables.Doing so will void system warranty.

This is the available information regarding this cable. While Trimble has taken care to prepare this information, we cannot be responsible for its accuracy.

The information supplied is for trouble shooting purposes only and not used to construct cables. Doing so will void system warranty.

EZ-Steer Platform Kit - Steigers, Versatile
This bracket attaches to the vehicle steering column to provide support for the steering motor for either the Trimble® AgGPS® EZ-Steer® assisted steering system or the EZ-Steer 500 system.
Supported Vehicles:
Versatile Buhler Tractors

NAV-900 Standard Multi Purpose mount plate

Fixes to Trimble Spar mounts or can be used with VHB taped mount feet for universal applications to a wide range of agricultural vehicles

Note:VHB taped mounting is not recommended for high-precision auto guidance installations as some cabs can have flexibility in their structure, for ultimate performance a more rigid option is preferred

Optional Vehicle Specific NAV-900 mount plates are also available - (See Specialty Roof Brackets section)

This harness allows GPS NMEA data to be output from FjDynamics' autosteer systems into other controllers... I.E. for Air-drills, Planters, Sprayers, etc.
Connector is standard 9-pin serial.

Receiver brackets. Fits all current (CoreNav, WiNav) FjDynamics Receivers. Self aligning. Come with double sided table for mounting.

CAN terminator used on FieldIQ cab harnesses.
