Note: The cable schematic information was best available at time of posting, however modifications in production can occur.
The information supplied is for troubleshooting purposes only, it is not intended to be used to construct cables.Doing so will void system warranty.

This is the available information regarding this cable. While Trimble has taken care to prepare this information, we cannot be responsible for its accuracy.

The information supplied is for trouble shooting purposes only and not used to construct cables. Doing so will void system warranty.

EZ-Steer Platform Kit - Steigers, Versatile
This bracket attaches to the vehicle steering column to provide support for the steering motor for either the Trimble® AgGPS® EZ-Steer® assisted steering system or the EZ-Steer 500 system.
Supported Vehicles:
Versatile Buhler Tractors

NAV-900 Standard Multi Purpose mount plate

Fixes to Trimble Spar mounts or can be used with VHB taped mount feet for universal applications to a wide range of agricultural vehicles

Note:VHB taped mounting is not recommended for high-precision auto guidance installations as some cabs can have flexibility in their structure, for ultimate performance a more rigid option is preferred

Optional Vehicle Specific NAV-900 mount plates are also available - (See Specialty Roof Brackets section)

This harness allows GPS NMEA data to be output from FjDynamics' autosteer systems into other controllers... I.E. for Air-drills, Planters, Sprayers, etc.
Connector is standard 9-pin serial.

Receiver brackets. Fits all current (CoreNav, WiNav) FjDynamics Receivers. Self aligning. Come with double sided table for mounting.

CAN terminator used on FieldIQ cab harnesses.

#4 Motor Spline Hub. Fits all John Deere; Fits all Versatile; Fits all small-frame CNH tractors;

For use with Standard Multi Purpose mount plate and also the Generic Quick Release solution

Ideal for universal application to a wide range of agricultural vehicles

Note:VHB taped mounting is not recommended for high-precision auto guidance installations as some cabs can have flexibility in their structure, for ultimate performance a more rigid option is preferred

***Three per Base Required, sold as singles /w hardware***

Basic activation license required to use NAV-960.
